Concurrent Technologies TR L9x/9sd-AFT – Air Flow Thru 3U VPX Processor Plug In Card

cct_tr-l9x-9sd-afta

Features

  • 8-core processor for high performance
  • 100G Ethernet Data plane
  • PCI Express Expansion plane for high-speed communication with adjacent board(s)
  • XMC site for additional I/O resources
  • Optional M.2 module for storage with Write/Protect and Opal 2.0 compliance

TR L9x/9sd-AFT has been designed in alignment with the SOSA™ Technical Standard for I/O intensive processor Plug-In Cards (PICs) and is fitted with an 8-core Intel® Xeon® W-11865MRE processor.  The integral GPGPU engine has 32 Execution Units which can be used for display or acceleration purposes using OpenCL™, OneAPI or OpenVINO™ for image processing or Artificial Intelligence. TR L9x/9sd-AFT supports up to 100GBASE-KR4 Ethernet capability which makes it suitable for many future applications needing high throughput communications.  TR L9x/9sd-AFT supports a range of standard security capabilities including Boot Guard, Total Memory Encryption, and is fitted with a Trusted Platform Module for key storage.  In addition, Concurrent Technologies offers an additional Guardian Package for enhanced security.

Datasheet TR L9x/9sd-AFT
