WINSYSTEMS PS-RS25-5

WINSYSTEMS PS-RS25-5
Contact us for more information

Features

  • Universal AC input: 88 to 264 VAC
  • Output voltage: +5V @ 5A full load
  • No fan required, convection cooling
  • Short circuit protection
  • Overload and overvoltage protection
  • Withstands 300 VAC input surge for 5 seconds
  • Complies with safety, EMI, and EMS standards
  • Power-on LEDs provide visual status of power

WINSYSTEMS’ PS-RS25-5 is a small, convection cooled 25W power supply for embedded systems. It is a universal design that accepts 88 to 264VAC input and generates up to 5A of current at +5 volts. The +5 volt output can be adjusted with an on board trimpot. The PS-RS25-5 is small, measuring only 79 x 51 x 28mm.

Datasheet PS-RS25-5
