Darveen Compact Embedded Computer Intel® Celeron™ J1900

drv_ebc-1122-v2a
drv_ebc-1122-v2adrv_ebc-1122-v2b
Contact us for more information

Features

  • Intel® Celeron™ Processor J1900 (2.0 GHz)
  • up to 8GB DDR3L 1333 MHz SDRAM
  • 1x COM Port (RS-232)
  • 2x GbE, 6x USB, 1x VGA, 1x HDMI
  • 1x 2.5″ SATA HDD/SSD, 1x mSATA
  • 1x MiniPCIe
  • 1x Audio out
  • 12V DC Power Input

Darveen's EBC-1122-V2 is a compact industrial embedded computer with rich I/O, high flexibility, easy MiniPCIe expansion capabilities, wide-input power ranges, wide temperature ranges, and a strong housing structure.

Datasheet EBC-1122-V2
